保护铝膜反射镜

技术规格:

材料..............................................................H-K9L优,融石英

尺寸公差...............................................................±0.20mm

厚度公差...............................................................±0.20mm

有效孔径....................................................................>90%

面形.........................................................................见下表

平行度...........................................................<3 arc minutes

光洁度........................................................................60-40

镀膜.......................S1面镀保护铝膜,Ravg>87%@400~800nm

P/NSizeFlatnessSubstrate
50201Φ12.7×5λ/4BK7
50202Φ25.4×5λ/4BK7
50203Φ12.7×6λ/10Fused Silica
50204Φ25.4×6λ/10Fused Silica
50205Φ12.7×6λ/20Fused Silica
50206Φ25.4×6λ/20Fused Silica
●尺寸单位:毫米
●其他规格和镀膜要求请联系EastOptics销售获得。
